PDP-504PU
94
1234
1234
C
D
F
A
B
E
AN16003A-K (50 SCAN A ASSY : IC3001 - IC3006)
(50 SCAN B ASSY : IC3201 - IC3206)
Plasma Display Panel IC
Pin Arrangement (Top view)
