Page #54 background imageLoading...
Page #54 background image
Basic playback
05
54
En
wireless technology, you can listen to music on a device
not equipped with
Bluetooth
wireless technology. The AS-
BT100 model supports SCMS-T contents protection, so
music can also be enjoyed on devices equipped with
SCMS-T type
Bluetooth
wireless technology.
Remote control operation
The remote control supplied with this unit allows you to
play and stop media, and perfor m other operations.
1
Pairing the
Bluetooth
ADAPTER and
Bluetooth
wireless technology device
“Pairing” must be done before you start playback of
Bluetooth
wireless technology content using the
Bluetooth
ADAPTER. Make sure to perform pairing the first time you
operate the system or any time pairing data is cleared. The
pairing step is necessary to register the
Bluetooth
wireless
technology device to enable
Bluetooth
communications.
2
For more details, see also the operating instructions of
your
Bluetooth
wireless technology device.
1 Set the remote control to the receiver operation
mode, then press
HOME MENU
.
2 Select ‘
System Setup
’, then press
ENTER
.
3 Select ‘
Other Setup
’, then press
ENTER
.
4 Select ‘Pairing Bluetooth Device’, then press ENTER.
5 Select the ‘
Passcode
’ setting you want.
Select the same passcode as the Bluetooth wireless
technology device you wish to connect.
0000/1234/8888 – Select the passcode from these
options. These are the passcodes that can be used in
most cases.
Others – Select to use a passcode other than those
mentioned above.
6 If you selected
Others
in step 5, enter the passcode.
Use
/
to select a number and
/
to move the cursor.
7 Follow the instructions displayed on the GUI screen
to conduct pairing with the
Bluetooth
wireless
technology device.
Switch on the Bluetooth wireless technology device that
you want to make pair, place it near the receiver and set
it to the pairing mode.
8 Check to see that the
Bluetooth
ADAPTER is
detected by the
Bluetooth
wireless technology device.
When the Bluetooth wireless technology device is
connected:
CONNECTED appears in the receiver display.
3
When the Bluetooth wireless technology device is not
connected:
Go back to the passcode setting in step 5. In this case,
perform the connection operation from the Bluetooth
wireless technology device.
9From the
Bluetooth
wireless technology device list,
select
Bluetooth
ADAPTER and enter the Passcode
selected in step 5.
4
Listening to music contents of a
Bluetooth
wireless technology device with your system
1
SC-LX83 only:
Set the remote control operation
selector switch to
SOURCE
.
2 Press
ADAPTER
on the remote control to switch the
receiver to
ADAPTER PORT
input.
5
3From the
Bluetooth
wireless technology device,
perform the operation to connect to the
Bluetooth
ADAPTER.
4 Start playback of music contents stored on the
Bluetooth
wireless technology device.
This receiver’s remote control buttons can be used for
basic playback of files stored on Bluetooth wireless
technology devices.
6
SC-LX83:
SC-LX73:
The Bluetooth
®
word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Pioneer Corporation is under license.
Other trademarks and trade names are those of their
respective owners.
5 While listening to a source, set the remote control
to the receiver operation mode, then press
STEREO
repeatedly to select
SOUND RETRIEVER AIR
.
Note
1 • It must be necessary that the Bluetooth wireless technology enabled device supports AVRCP profiles.
• Remote control operations cannot be guaranteed for all Bluetooth wireless technology enabled devices.
2• Pairing is required when you first use the Bluetooth wireless technology device and Bluetooth ADAPTER.
• To enable Bluetooth communication, pairing should be done with both your system and Bluetooth wireless technology device.
3 The system can display alphanumeric characters only. Other characters may not be displayed correctly.
4 The passcode may in some cases be referred to as PASSKEY or PIN code.
5 When the Bluetooth ADAPTER is not plugged into the ADAPTER PORT, NO ADAPTER will be displayed if ADAPTER PORT input is selected.
6• Bluetooth wireless technology device should be compatible with AVRCP profile.
• Depending on the Bluetooth wireless technology device you use, operation may differ from what is shown in the remote control
buttons.
SOURCE
TV
RECEIVER
VOL
VOLCH
STATUS
THX PQLSMPX MEMORY
PHASE CTRL CH LEVEL
PGM MENU
STEREO
AUTO/ALC/
DIRECT
STANDARD ADV SURR
HDMI OUT
TV
/
DTV MPX PQLS
PHASE
CTRL STATUSTHX
STEREODIRECT
STANDARD
ADV SURR
AUDIO
HDD DVD
213
SC-LX83_73_DLPW.book 54 ペー 105月9日 水曜 午2時
