Pioneer SVM-1000 Service Manual

170
SVM-1000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
10.42 VOLTAGES
Measurement Condition
Input connectors DVD/LINE Nothing
PHONO Nothing
DIGITAL IN Nothing
MIC1 Nothing
MIC2 Nothing
Output connectors MASTER1 Nothing
MASTER2 Nothing
REC Nothing
BOOTH Nothing
DIGITAL OUT Nothing
HP Nothing
MIC MIC LEVEL1 Max.
MIC LEVEL2 Max.
MIC EQ HI Center
MIC EQ LOW Center
MIC OFF
FADER ST. All Ch OFF
HP HP MONO/STEREO STEREO
MIXING Center
LEVEL Max.
CH INPUT SELECT All Fully counter clock wise direction
TRIM Max.
EQ HI Center
EQ MID Center
EQ LOW Center
VIDEO TRIM Center
CUE OFF
FADER Max.
CROSS FADER ASSIGN All Ch THRU
CROSS FADER ASSIGN Center
MASTER LEVEL Max.
BALANCE Center
CUE OFF
MONO/STEREO STEREO
BOOTH MONITOR Max.
CH FADER CURVE Center
CRS FADER CURVE Center
REAR MASTER ATT 0 dB
DIGITAL OUT fs(Hz) 96 k
EFFECT AUTO/TAP AUTO
CUE OFF
EFFECT DERAY
CHANNEL 1
TIME -
ON/OFF OFF(Lighting)
