12. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k
Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..MAIN ASSY DWX2715
NSP1..SCIV ASSY DWM2302
2..SCPU ASSY DWX2716
2..INVT ASSY DWX2717
NSP 1..AUDI ASSY DWM2303
2..AUD1 ASSY DWX2718
2..DIO2 ASSY DWX2719
2..USB1 ASSY DWX2727
NSP 1..AUIL ASSY DWM2304
2..AUD2 ASSY DWX2721
2..ILMR ASSY DWX2722
2..ILML ASSY DWX2723
NSP 1..DIHP ASSY DWM2305
2..USB2 ASSY DWX2720
2..DIO1 ASSY DWX2724
2..PDIV ASSY DWX2725
2..HAMP ASSY DWX2726
2..SDIO ASSY DWX2728
2..MIDI ASSY DWX2751
2..REG ASSY DWX2767
NSP 1..CTVI ASSY DWM2306
2..CTL1 ASSY DWX2729
2..CTL3R ASSY DWX2730
2..VIO1 ASSY DWX2731
2..VIO2 ASSY DWX2732
2..VIN3 ASSY DWX2733
2..HJCK ASSY DWX2734
NSP
1..CTFD ASSY DWM2307
2..CTL2A ASSY DWX2735
2..CTL2B ASSY DWX2736
>
2..ACSW ASSY DWX2737
2..MJCK ASSY DWX2738
2..CRFD ASSY DWX2739
2..CFD1 ASSY DWX2740
2..CFD2 ASSY DWX2741
2..CFD3 ASSY DWX2742
2..CFD4 ASSY DWX2743
2..CTL3LA ASSY DWX2744
2..CTL3LB ASSY DWX2745
>
1..Power Supply Unit DWR1440
Mark No. Description Part No.
A
AUD1 ASSY
SEMICONDUCTORS
IC 4001,4004,4011,4013 NJM4580MD
IC 4002,4005,4007,4018 TC7SET08FUS1
>
IC 4003,4020,4035 LTC1590CS
IC 4006,4008,4010 TC7SH08FUS1
IC 4009 AK5381VT
IC 4012,4045,4046 NE5532AD
IC 4014,4016,4026-4029 NJM4580MD
>
IC 4015,4030,4057,4058 LM4040EIM3-2.5
>
IC 4017,4032 CS5361-KS
IC 4019,4022,4033,4034 TC7SET08FUS1
IC 4021,4036 OPA2134UA
IC 4023-4025,4038-4040 TC7SH08FUS1
IC 4031 NJM4580MD
IC 4037,4041-4043,4049 TC7SET08FUS1
IC 4044 AK4382AVT
IC 4047,4048 NJM5532DD
IC 4050-4055 TC7SH08FUS1
IC 4056 TC7SET08FUS1
Q 4001-4004,4014 2SC4081
Q 4005-4008 2SK371D1
Q 4009-4013 DTC124EUA
Q 4015-4022 2SC3326
D 4001-4010,4012,4013 1SS355
D 4011,4018 UDZS5R6(B)
D 4014-4017,4021-4024 RB706D-40
D 4019,4020 1SS355
MISCELLANEOUS
F 4001-4005 FERRITE CORE VTF1093
JA 4001,4007,4008 HEADPHONE JACK DKN1281
JA 4003,4005 JACK VKB1133
JA 4004,4006 JACK RKN1004
KN 4001,4002 WRAPPING TERMINAL VNF1084
RY 4001,4002 RELAY VSR1008
CN 4002 CONNECTOR POST B3B-PH-K-S
CN 4010 17P CONNECTOR DKN1511
CN 4011 34P CONNECTOR DKN1512
CN 4014 CONNECTOR POST S8B-EH
CN 4015,4016 19P CONNECTOR 19R-1.25FJ
