Mark No. Description Part No.
Mark No. Description Part No.
JA101–JA103 PIN JACK(6P) AKB7012
CN105 KR CONNECTOR B5B-PH-K-S
CN108 15P PLUG KM200TA15
CN113 7P PLUG KM200TA7
120–122 PCB BINDER VEF1040
FRONT ASSY
SEMICONDUCTORS
IC201 PDG254A
Q201, Q202 2SA933S
Q206, Q207 2SC1740S
Q203–Q205 KRC101M
D201–D221, D224–D226, D229 1SS355
COILS AND FILTERS
L201 LFA2R2J
SWITCHES AND RELAYS
S201, S202, S205–S214 ASG1034
S217–S224, S233–S235 ASG1034
S250 ASX7004
CAPACITORS
C204 ACH7017
C220–C222 CCSQCH101J50
C217 CCSQCH102J50
C206, C208 CEAT2R2M50
C212 CEAT470M25
C205 CEAT470M50
C202 CEAT471M6R3
C227 CEJA221M6R3
C201, C203, C211 CKSQYB103K50
C214–C216 CKSQYB104K25
C209, C210 CKSQYB473K50
C207 CKSQYF104Z25
RESISTORS
R230 RA8T103J
R225 RA9T104J
Other Resistors RS1/10S&&&J
OTHERS
201 REMOTE RECEIVER UNIT GP1U27X
204 4P CABLE HOLDER 51063-0405
CN201 15P FFC CONNECTOR 52044-1545
CN203 21P FFC CONNECTOR 52045-2145
CN202 26P FFC CONNECTOR 52045-2645
V201 FL TUBE AAV7062
X201 CERAMIC RESONATOR ASS1055
(7.7MHz)
POWER SW ASSY
SEMICONDUCTORS
D291 BR3371XJ30A
SWITCHES AND RELAYS
S291 ASG1034
RESISTORS
All Resistors RS1/10S&&&J
OTHERS
291 4P CABLE HOLDER 51063-0405
AMP ASSY
SEMICONDUCTORS
IC404, IC405 ICP-N25
IC701 NJM78M56FA
IC401, IC402 PAC007A
IC403 PAC008A
Q712 2SA992
Q1404, Q1405 2SC1740S
Q711 2SC1845
Q1402, Q403, Q404, Q453, Q454 2SC2240
Q405, Q406, Q455, Q456 2SC2705
Q1403, Q1434, Q407, Q408 2SC2878
Q457, Q458 2SC2878
Q1436, Q714 KRA103M
Q1435, Q701 KRC101M
Q713 KRC103M
D1401, D1403, D1435, D1436 1SS133
D401, D402, D405, D406 1SS133
D411, D412, D451, D452 1SS133
D455, D456, D461, D462 1SS133
D703–D705 1SS133
D711, D712, D717 D5SBA20(B)
D713, D714 MTZJ18B
D701 MTZJ5.1A
D702 S1WB20
COILS AND FILTERS
L701 LINE FILTER ATF-151
L1432, L1433 AF CHOKE COIL ATH1004
SWITCHES AND RELAYS
RY401 ASR7001
RY701 ASR7016
CAPACITORS
C704, C705 (10000pF/AC250V) ACG7020
C715, C716 (8200µF/71V) ACH7018
C1408, C1410 CCCSL101K2H
C1411, C1442, C415, C416 CCCSL221J50
C465, C466 CCCSL221J50
C1441, C439, C442–C444 CCCSL221K2H
C1420, C1421 CCCSL390J50
C437, C438, C479, C480 CCCSL470J50
C1403, C1404, C405, C406 CEANP2R2M2A
C455, C456 CEANP2R2M2A
C1415, C423, C424, C473, C474 CEANP2R2M50
C1402, C403, C404, C453, C454 CEANP4R7M50
C413, C414, C463, C464 CEAT100M50
C436, C486 CEAT101M10
C1405, C411, C412, C461, C462 CEAT101M25
C713, C714 CEAT101M2A
C702 CEAT102M25
C490, C717, C718 CEAT1R0M50
C1419 CEAT221M10
C701 CEAT470M25
