5
VSA-E03
1 INPUT Assy AWX7438
2 FRONT Assy AWX7439
NSP 3 POWER SW Assy AWX7222
4 REAR SP Assy AWX7251
5 AMP Assy AWX7446
NSP 6 HEADPHONE Assy AWX7230
7 TRANS 1 Assy AWX7287
8 TRANS 2 Assy AWX7292
NSP 9 FRONT VIDEO Assy AWX7241
10 BARRIER Assy AWX7284
NSP 11 F.SP.CONNECT Assy AWX7285
NSP 12 R.C.SP.CONNECT Assy AWX7286
13 VIDEO Assy AWX7441
14 SVIDEO Assy AWX7450
15 MECH SW Assy AWX7247
16 FRONT LARGE Assy AWX7245
17 DOLBY DIGITAL Assy AWX7196
18 Power Transformer (T1) ATS7242
19 Fuse (FU1 : T2.5A) REK-104
20 • • • • •
21 FFC 21P (J2) ADD7100
22 FFC 15P (J4) ADD7102
23 • • • • •
24 FFC 17P (J8) ADD7107
25 FFC 26P (J3) ADD7118
26 AC Power Cord See Contrast table (2)
NSP 27 8P Shield Cable (J6) ADX7243
28 Cord Stopper CM-22B
29 Tuner Holder B AAD7490
NSP 30 Under Base D5 ANA7079
31 Rear Panel ANC7859
32 Bonnet Case AZN7771
33 Trans Frame ANG7193
34 DSP Shield ANG7196
NSP 35 Heat Sink Assy D5 ANH7095
36 Insulator PNW2766
37 Locking Card Spacer AEC7160
38 PCB Mold AMR2533
NSP 39 Card Spacer DEC1770
NSP 40 Binder RNE1277
41 Volume Knob 508 AAB7179
42 Sub Panel 508 AAD7482
43 Function Button E03 AAD7543
44 Power Button AAD7440
45 Power Button M AAD7442
46 Display Window W5 AAK7594
47 Front Panel E03 AMB7647
48 • • • • •
49 Name Plate PAM1776
50 LED Lens PNW2019
51 • • • • •
52 • • • • •
53 Screw ABA7009
54 Screw ABA7043
55 Screw ABA7044
56 • • • • •
57 Screw BBZ30P080FZK
58 Screw BBZ30P200FMC
59 Screw BPZ30P080FMC
60 Screw FBT40P080FZK
NSP 61 Binder (BK-1) ZCA-BK1
62 Heat Sink Angle F ANG7194
63 Heat Sink Angle R ANG7195
NSP 64 Heat Sink D5 ANH7090
65 Screw BBZ30P080FMC
NSP 66 FET Assy AWX7228
67 • • • • •
68 Sheet AEE7026
69 FET Angle ANG7186
70 Fuse Holder See Contrast table (2)
71 Fuse (T5A) See Contrast table (2)
72 Screw ABA1007
73 FFC 11P (J7) ADD7142
74 Push Rivet AEC7025
75 Top Cover AME7375
NSP 76 Shrink Shield 140 PDM1021
77 • • • • •
78 Front Panel E03 Assy AMB7648
79 Cord Clamper RNH-184
(1) EXTERIOR PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
(2) CONTRAST TABLE
VSA-E03/HYXJI, HYXJI/GR and HVXJI are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
HYXJI Type HYXJI/GR Type HVXJI Type
26 AC Power Cord VDG1061 VDG1061 VDG1063
70
Fuse Holder
Not used Not used VKR1003
71
Fuse (T5A)
Not used Not used PEK1003
