51
VSA-E03
Note :• In the power off condition (with the remote control unit key or the main unit tact key), set to "L" excepting tuner mute (pin 54). However, it
nothing is done against to the input port.
• When pin 10 and 11 detect "L" at the reset, be careful because it enter the microcomputer's own test mode.
No. Pin Name I/O Pin Function Active
51 SVIDEO1
O TC4051 control (S terminal control) H52 SVIDEO2
53 SVIDEO3
54 TMUTE O Tuner mute H
55 VMUTE O Video mute L
56 CDREST O CS4226-KQ reset L
57 LC4966 O Input switch the DVD 6ch (L: DVD 5.1ch) H
58 ST_9174 O Strobe signal for communication with TC9174 H
59 AC3_9164 O Strobe signal for communication TC9164AF H
60 AC3RST O Reset the MUCAP L
61 AC3BST O During transfer the application data to MUCAP "H" H
62 RY_AC O AC relay ON/OFF H
63 RY_HP O Headphone relay ON/OFF H
64 RY_C/R O Rear/Center relay ON/OFF H
65 RY_A+B O Speaker A + B relay ON/OFF H
66 RY_B O Speaker B relay ON/OFF H
67 RY_A O Speaker A relay ON/OFF H
68 VHVL O Power switch for AMP system (H : VH) H
69 S22/KEY13
O
Segment output 22/key scan output 13
H
70 S21/KEY12 Segment output 21/key scan output 12
71 S20/KEY11 Segment output 20/key scan output 11
72 S19/KEY10 Segment output 19/key scan output 10
73 S18/KEY9 Segment output 18/key scan output 9
74 S17/KEY8 Segment output 17/key scan output 8
75 S16/KEY7 Segment output 16/key scan output 7
76 S15/KEY6 Segment output 15/key scan output 6
77 S14/KEY5 Segment output 14/key scan output 5
78 S13/KEY4 Segment output 13/key scan output 4
79 S12/KEY3 Segment output 12/key scan output 3
80 S11/KEY2 Segment output 11/key scan output 2
81 S10/KEY1 Segment output 10/key scan output 1
82 S9
O
Segment output 9
H
83 S8 Segment output 8
84 S7 Segment output 7
85 S6 Segment output 6
86 S5 Segment output 5
87 S4 Segment output 4
88 S3 Segment output 3
89 VDD − 5V
90 S2
O
Segment output 2
H
91 S1 Segment output 1
92 G11 Grid output 11
93 G10 Grid output 10
94 G9 Grid output 9
95 G8 Grid output 8
96 G7 Grid output 7
97 G6 Grid output 6
98 G5 Grid output 5
99 G4 Grid output 4
100 G3 Grid output 3
