Pioneer VSA-E03 - Page 55

VSA-E03
55
Mark No. Description Part No.
SEMICONDUCTORS
IC1 AZC7282
Q1 2SC3265
D1 SE303A-C
D2 RLS-73
D9-D17 CL-230HR-CD
CAPACITORS
C1 CEAT470M10
C2 CEAT221M6R3
C3,C4 CEATR10M50
RESISTORS
R1 RS1/8S1R8J
Other Resistors RS1/10S J
OTHERS
X1 CERAMIC RESONATOR KBR-4.0M
(4MHz)
7.3.4 PCB Parts List
NOTES: ¶Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
¶The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
¶When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω = 56 × 10
1
= 561 ........................................................ RD1/4PU 5 6 1 J
47k Ω = 47 × 10
3
= 473 ........................................................ RD1/4PU 4 7 3 J
0.5 Ω = R50 ..................................................................................... RN2H Â 5 0 K
1 Ω = 1R0 ..................................................................................... RS1P 1 Â 0 K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω = 562 × 10
1
= 5621 ...................................................... RN1/4PC 5 6 2 1 F
