Pioneer XR-P310 User Manual

| IMPORTANT
imangle, is intended to alert the user to the presence of
umnsuiated “dangerous voltage” within the product's
enclosure that may be of sufficient magnitude to consiaute
a tisk of electric shock to persons
| The lightning fiash with arrowhead, within an equitateral
CAUTION
RISK-OF ELECTRIC:'SHOCK
‘DO-NOT_OPEN? 25
CAUTION:
‘TO PREVENT THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER {OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The exclamation point within an equilateral triangie is
intended to alert the user to the presence of important
oerating anc maintenance iservicingt instructions in|
the literature accompanying the appliance. |
READ INSTRUCTIONS ~ All the safety and operating
instructions should be read before the appliance is
operated.
RETAIN INSTRUCTIONS — The operating snstructions
should be retained for future reference
HEED WARNING —Aliwarnungs.on the appliance andin
the aerating instructions should be adhered to.
FOLLOW INSTRUCTIONS — All operating and use in:
structions should be totlowed.
WATER AND MOISTURE - The appliance snouid not
be used near water ~ for example, near a bathtub,
washbow|, kitchen sink, laundry tub, in a wet base:
ment, or near a swimming pool, etc
LOCATION - The apptiance should be instalied in a
stable location
WALL OR CEILING MOUNTING - The appliance
should not be mounted to a walt or ceiling
VENTILATION ~ The apphance should be situated so
that is location or position does not interfere with
its praper ventilation. For example, the appliance
shoutd not be situated on a bed, sofa. rug, oF similar
surface that may block the ventilation openings: oF,
placed in a built-in instatiation, such as a bookcase
oF cabinet that may impede the flow of air enrough
the ventifation openings
HEAT - The appliance should be situated away from
heat sources such as radiators, heat registers,
stoves, or cther appliances {including ampiitiers?
that produce heat
POWER SOURCES ~ The appliance shouid be con-
nected to @ power supply only of the toe de
scribed in the operating instuctions or as marked
on the appliance
POWER-CORD PROTECTION -- Powersupply coras
should be routed so that Mhey are not tikely to be
watked on oF pinched by items placed upon or
against them Pay particular attention to cords at
piugs. canvemence receptacles, and the point
where they exit from the appliance
POLARIZATION ~ if your purchased product 1s pro
video with a polarized power plug, please read the
following instructions. Ths prodyct is equipped
with a polarized alternating currentiine plug la plug
having one blade wider thao the other This plug
will fit into the power outer only one way This is a
safety feature. If you ase unable to insert the plug
fully into the outiet. ty reversing the plug. If the
Plug shoutd stilt tail to fir, contact your electrician to
replace your obsolete outler Do not defeat the
safety purpose of the polarzed plug
CLEANING - The appliance should be cteanea only
with 2 polistang cloth oF 8 sott dry cloth. Never
clean with fureiture wax, benvine, Insecticides oF
otner volatile liquids since they may corrode the
cabinet.
SAFETY
INSTRUCTIONS
POWERLINES ~ An outdoor antenna should be located
away from power lines.
NONUSE PERIODS - The power cord of the appliance
Should be unplugged (rom the outlet when left un-
used for a long periad of time
OBJECT AND LIQUID ENTRY Care should be taken
50 that objects do nat fall and liquids are not spilled
into the enclosure through openings.
DAMAGE REQUIRING SERVICE — The appliance
should be serviced by a Pioneer authorized service
center or qualified service personnel when:
‘The power supply cord or the plug has been dam:
aged
Objects have fatien, of liquid has been spilled into
the apphance
‘The anptiance has oeen exposed to rain,
The appliance does not appear to operate normally
o¢ exhibits 3 marked change in performance.
The apphence has been crapped or the enclosure
damaged
SERVICING ~ The user snould not atiempt to service
the apphance beyond that described in the opera-
Hing nstrucbons. For all other servicing, contact the
nearest Pioneer authorized service center,
@ ee © 6
ELECTRIC
SERVICE
EQUIPMENT —
ANTENNA,
DISCHARGE UNIT
INEC SECTION 810 — 20} '
L GROUNDING CONDUCTORS
iNEC SECTION 810 - 21)
<S=— GROUND CLAMPS,
woo> POWER SERVICE GROUNDING
ELECTRODE SYSTEM
FIG. A «NEC ART 250, Pai
OUTDOOR ANTENNA GROUNDING ~ If an outsice an.
Tenna 1s connected tothe antenna terminal, be sure
the antenna system is grounded s0 as to provide
some protection against voltage surges ané Suit
up static charges
In the US A section BI0 of the National Electrica
Code. ANSUNFPA No, 70-1884, provides informa
tion with fespect to proper grounding of the mast
and supporting structure, grounding of tne iead-in
wire to an antenna discharge uns, size of grounding
conductors, location of antenna discharge unit
connection {0 grounding electrodes, and require-
ments for the grounding eiectrode. See Fig A
CART ~ An apptiance and cart combination should be
moved with care Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart
combination to overturn.
NEC - NATIONAL ELECTRIC CODE
