Figure 1 Items
#
ITEM
DESCRIPTION
1
Display
Display all the operation information
2
Holder
Handpiece holder
3
Fiber
Laser energy is transported through the
fiber
4
Indicator
Power(Green)/Notation(red)/Laser(Yellow)
5
Emergency Stop Button
Disables the device In the Event of an
Emergency
6
Fiber Spool
Stores Fiber
7
Handpiece
Treatment Handpiece
8
Handle
For Transporting the Unit
9
Handpiece Port
Connects Handpiece
10
Fiber Port
SMA 905
