8.4 Notation system detection
The user can determine whether the notation system is normal by self-test: For
example, if the user unplug the remote interlock, the system will sound, notation
indicator, graphical warning signs and other notation status. After verifying the
notation system is normal, please restore the remote interlock.
8.5 Fault Diagnosis and Analysis
Failure
phenomenon
Cause Analysis
Exclusion method
Turn on the
power switch,
the system
indicator does
not light and
the system
does not start
Emergency stop switch is not
turned on;
Release of emergency stop switch;
The screen
displays an
notation
1. Remote control interlock is
not connected;
2.The foot switch is not
connected;
3.Fiber is not connected
4.Laser failure;
5.Battery is low
1.Check whether the remote interlock is
connected properly;
2. Check the Foot switch is connected
properly;
3. Check whether the fiber is connected
properly;
4.Use external power supply
5.Contact the company for after-sales
maintenance;
There is no
sound
indication when
1.Buzzer malfunction
Contact the company for after-sales
maintenance;
WARNING
Do not use the device for treatment when the device is malfunctioning or in
other abnormal conditions. Please promptly in accordance with the
instructions for the troubleshooting and contact the company for
after-sales advice.
