USER MANUAL Page 24 of 69
Place the main unit of
H1
on a suitable table, cart, and shelf top, etc. with a
minimum distance of 200 mm to the surroundings. Attach all items in place in the
following steps.
A. Insert the power cable on the power adapter to the socket which is on the left side
of the main unit.
B. Connect one end of the power cord to the power adapter and the other end to the
power supply.
C. Connect the remote door interlock.
Insert the remote door interlock in the port which is on the left side of the unit. The
interlock is potential-free at a maximum 5 VDC and maximum 10 mA. If the remote
interlock is connected to an external port (such as the door contact), it shut down the
laser beam when the door is opened so that persons entering the room are not
harmed.
When the unit is first-time delivered, it is equipped with a short connection on the
interlock.
Remove the short connection and connect it to the remote door interlock.
Electricity - Electrical shock
Turn off the unit first and unplug its main power supply before installing
the remote door interlock to avoid electrical shock.
Note
The external contact must be potential-free and designed for at least 12 V
DC and 100 mA.
