Page 25 of 69 USER MANUAL
Figure 2 The connecting positions of power adapter and remote interlock.
D. Carefully take the fiber roller out of package and check for damage.
The fiber cable is about 3 meters long. DO NOT allow the fiber to be bended with
radius less than 50mm.
E. Connect the fiber cable with the handpiece.
See
5.4 Instruction for using the handpiece.
F. Mounting the fiber roller as below instruction
Figure 3 The fiber holder
