G. Attach the other end of the fiber to the SMA socket on the main unit.
Remove the protective cap of the SMA905 connector. Hold the metal plug in your
hand and do not pull on the fiber.
Unscrew the protective cap of the SMA socket on the unit.
Insert the SMA connector of the fiber completely into the SMA socket and screw
the union nut tight. Do not twist the fiber!
H. Turn on the unit and check the optical quality of the fiber output via the red aiming
beam by shining the red beam onto a piece of white paper.
The edge of the aiming beam spot should not be "frayed." A frayed edge indicates
defects or soiling of one or both fiber ends.
See also: 5.3 Cleaving the fiber
I. Connect the foots pedal cable to the unit.
Note
To protect the optical components in the device, the SMA905 socket in the
unit must always be closed (with either a fiber cable or a protective cap).
Note
Only use fibers with clean fiber ends.
See also:
5.4 Instruction for Using the Handpiece
Note
The fiber plug must be correctly screwed into the SMA socket to keep the
light fiber from premature aging. Check this by moving the plug back and
forth in an axial direction near the kink protection. Axial play means that the
bare fiber is not correctly connected to the unit.
