Piper PA-39 Twin Comanche C/R - Engine and Engine Accessories - Fuel and Oil Systems

TWIN COMANCHE C/R
B. Engine and Engine Accessories - Fuel
and Oil Systems
Two Engines
d Lycoming Model 10-320-B 1 A (L)
L Lycoming Model LIO-320-B 1A (R)
Two Oil Coolers, PAC Dwg. 18622,
Harrison Model No. AP07AU06-03
Installed in accordance with
-.-is. PAC Dwg. 24086
Two Fuel Pumps - Engine Driven
x AC Type JT Model 6440296 (L)
,L AC Type JT Model GP6440296 (R)
Two Fuel Pumps - Elec. - Rotary
Weldon Model No. B8 1 OOCC (L) -
q Per PAC Dwg. 24058-S
Weldon Model No. B8 1 OOC (R) -
Per PAC Dwg. 240584
Weldon klel No. 24058-7 (L) -
Per PAC Dwg. 24058-7
Weldon Model No. 240586 (R) -
Per PAC Dwg. 24058-6
TiGo Starters - 12V
A Prestolite Model MZ-4206 (L)
PC .Prestolite Model MZ42 16 (R)
Two Vacuum Pumps
Airborne Mechanisms Model
l L 2oOCc (L)
Airborne Mechanisms Model
* Y 200CW (R)
Two Hydraulic Governors
Hartzell Model F-6-3A per
L PAC Dwg. 16564-7 (L)
Ha&e11 Model F-6-3AL per
-m-&m PAC Dwg. 16564-8 (R)
Two Induction Air Filters Fram
A Model CA144PL
ISSUED: November 28,1%9
REISSUED: June 1,197O
RJZVISED: November 30,197l
Weight
Arm Aft Cert.
Lbs.
Datum
Basis
293.0 ea.
45.8
TC 1ElZ
2.1 ea.
62.3
TC AlEA
2.0 ea.
58.0
TC IE
2
3.0 ea.
90.0
TC AlEA
3.0 ea. 90.0
,+
TCAlEA
.
18.0 ea. 37.0
TCAlEA
3.5 ea.
58.9
TC AlEA
4.6 ea.
0.7 ea.
61.8
57.0
TCP9EA
TC AlEA
REPORT: 1605 PART II PAGE 11
MODEL: PA-39
