PART DESCRIPTION PART DESCRIPTION
1 Grill Hood 37 Door Handle
2 Hood Hinge Screw 38 Left Cabinet Door
3 Temperature Gauge Bezel 39 Right Cabinet Door
4 Temperature Gauge Heat Insulating Spacer 40 Match Light Tool
5 Temperature Gauge 41 Match Light Holder
6 Hood Bumper 42 LP Tank Barrier Bar
7 Hood Handle Bezel Heat Insulating Spacer 43 Caster
8 Hood Handle Bezel 44 Locking Caster
9 Hood Handle 45 Door Catch Plate
10 Hood Bracket, Left 46 Cart Base
11 Hood Bracket, Right 47 LP Tank Bolt
12 Grill Firebox 48 Right Side Cart Panel
13 Door Top Pivot Bracket 49 Side Burner Plate
14A Control Panel Bracket, Left 50 Right Shelf Bracket
14B Ignition Heat Shield 51A Right Shelf Front
15 Control Panel Bracket, Right 52 Right Shelf Base
16 Main Gas Manifold Assembly 53 Side Burner Pan
17 Electronic Igniter 54 Side Burner Igniter
18 Control Panel 55 Side Burner Grate
19 Control Knob 56 Side Burner Lid
20 Bezel 57 Side Burner Lid Hinge
20A Side Burner Bezel 58 Main Burner
21A Gas Hose 59 Main Burner Electrode & Wire D
22 Side Burner Gas Manifold Assembly 60 Main Burner Electrode & Wire C
23 LP Hose and Regulator 61 Main Burner Electrode & Wire B
24 Grease Tray 62 Main Burner Electrode & Wire A
25 Grease Cup 63 Cotter Pin
26 Back Grill Head Cover 64 Flame Tamer
27 Cart Heat Shield 65 Cooking Grate
28 Cart Back Panel 66 Warming Rack
29 Left Shelf Bracket 67 Instruction Manual
30 Left Shelf Base 68 Complete Hardware Pack
31 Left Shelf Front 69 Screw – 5/32-32 x 3/8 inch (AA)
32 Left Side Cart Panel 70 Screw – 1/4-20 x 1/2 inch (BB)
33 Cart Support Beam 71 Screw – 1/4-20 x 3/8 inch (CC)
34 Cart Support Bracket 72 Lock Washer – 1/4-20 (DD)
35 Door Magnet 73 Screw – 1/4-20 x 5/16 inch (EE)
36 Door Handle Grommet 74 Allen Wrench (FF)
