14 ReplacingtheBasketLiftComponents
14.1 Removing the Basket Lift Cover
1. Remove the six (6) screws, which hold the
back of the basket lift cover, using a 5/16 inch
socket.
2. Lift up the back and remove.
14.2 Replacing the Basket Lift Transformer
1. Remove the two (2) screws, which hold the
transformer, using a 5/16 inch socket.
2. Remove all wires on transformer box using
needle-nose pliers.
Follow steps 1 through 2 in reverse to reinstall
new transformer box.
