Pitco SELV Series - General

L22-393 R0 Page 9
25.14 Export and CE Wiring Diagrams (3 Phase Twin WYE Vat) ............................................ 94
25.15 Export and CE Wiring Diagrams (3 Phase Twin Delta Vat) ............................................ 95
2 General
Read the instructions in this manual thoroughly before attempting to operate this equipment. This
manual covers all configurations of Pitco SELV electric models. The fryers in this model family have
most parts in common, and when discussed as a group, will be referred to as SELV fryers.
The SELV fryers feature a low oil volume frying vat, optional automatic oil top off and optional
automated filtration unit. The Solstice design features a large round drain, which ensures that fries and
other debris will be washed into the filter pan. The SELV fryers are controlled with an I12 + Controller.
Fryers in this series come in full- or split-vat arrangements, and can be purchased in batteries of up to
five fryers.
