nSHUTTLE LT
Hardware
NUMBER PART NUMBER DESCRIPTION TORQUE *
4 FP-UDH-TA-12MM-BLK-V1-R1 Universal Rear Derailleur Hanger
5 - Universal Rear Derailleur Hanger Bolt 25 Nm (18 lb·ft)
6 - Universal Rear Derailleur Hanger Washer
7 FP-LNK-UL-84MM-V1-R1 84mm Upper Link
8 FP-LNK-LL-50MM-V2-R1 50mm Out-to-Out Lower Link V2
9 FP-BRG-6902-LLUMAXECN 28mm 6902 Extended Max-E Bearing R
10 FP-BRG-6902-LLUMAX 28mm 6902 Standard Max Bearing R
11 FP-BRG-6900-LLUMAXE 22mm 6900 Ext'd Max-E Bearing R
12 FP-BLT-M8*45.7-BLK-V2 M8 Front Shock Bolt for 30.1mm Shock Spacing 13 Nm (10 lb·ft) G / L
13 FP-BLT-M14*20-BLK-V2-R2 M14x20 Link Bolt 35 Nm (27 lb·ft) L
14 FP-BLT-M14*20-BLK-V4-R1 M14x20 Link Bolt w/ Internal Threads 35 Nm (27 lb·ft) L
15 FP-BLT-M10*16.5-BLK-V1 M10 Trunnion Mount Bolt 13 Nm (10 lb·ft) L
16 FP-SCW-FLT-M8*16 M8x16 Flat Head Bolts for Skid Plate 13 Nm (10 lb·ft) G / L
17 FP-BLT-M14*20-BLK-V3-R2 M14x20 Flip Chip Bolt 35 Nm (27 lb·ft) L
18 FP-NUT-FLIPCHIP-4.6MM-V1 4.6mm Flip Chip G
19 FP-WSH-SPC-15I*25O*3W M14x3mm Flip Chip Spacer G
20 FP-CLM-MECH-FRM-V1 Internal Routing Cable Clamp
21 FP-CVR-MECH-FRM-V2 Internal Routing Hole Cover
22 FP-CLM-DUAL-FRM-V1 Internal Routing Dual Clamp
23 FP-CLM-MECH-FRM-V2 Internal Routing Cable Clamp (Mirrored)
24 FP-SCW-FLT-M3*10 M3x10 Cable Clamp Screw (Included w/ Clamp)
25 FP-CLM-DI2-SLV-BLK-V1 Di2 Wire Sleeve for Cable Clamps
26 FP-CLM-ADEL-5MM-V1-R1 5mm Adel Clamp for Rear Brake
27 PIVOT WB BOLTS V2 M5 Adel Clamp Bolt / Top Tube Tool Bolts
28 FP-CLM-ADEL-4MM-V1-R1 4mm Adel Clamp for RD Cable
29 FP-SCW-BTN-M4*8-V1-R1 M4x8 Adel Clamp Mounting Bolt
30 FP-GDE-DI2-7*8*2.5*2.5 7x8mm Di2 Wire Guide
31 FP-MNT-CG-V3 Chain Guide Mounting Plate
32 FP-SCW-FLT-M5*12 M5x12 CG Mounting Screw 5 Nm (4 lb·ft) L
33 FP-SCW-SCK-M8*25-V1-R1 M8x25 Motor Mounting Screw 13 Nm (10 lb·ft) L
34 FP-SCW-SCK-M8*30-R1 M8x30 Motor Mounting Screw 13 Nm (10 lb·ft) L
35 FP-WSH-8I*12O*1W M8 Motor Mount Bolt Washer
36 FP-WSH-SKIDPLT-V1-R1 M8 Bushing for Rear Skid Plate bolts G
37 FP-SPC-SKIDPLT-WEDGE-V1-R1 Skid Plate Wedge
38 FP-PRO-SKIDPLT-WEDGE-V1-R1 Skid Plate Wedge Rubber
39 FP-GDE-BATT-LOWER-V1-R1 Lower Battery Support
40 FP-MNT-WIRE-PLATE-V1-R1 Wire Connector Custom Backing Plate
41 FP-BLT-FLT-M6*16-V1-R1 M6x16 Skid Plate Wedge / Front Bracket mounting bolts G / L
42 FP-NUT-M6-NYLOC-V1-R1 M6 Nylon Locking Nuts
43 FP-MNT-FRNT-BATT-V3-R1 Front Battery Bracket
44 FP-MNT-LATCH-BATT-V1-R1 Front Battery Catch
45 FP-BLT-BTN-M5*6-V1-R1 M5x6 DT Water Bottle Bolts 3 Nm (26 in·lb)
46 FP-GDE-WIRE-PLATE-V1-R1 Wire Routing Plate
47 FP-PRO-FOAM-87*21-V1-R1 Wire Routing Plate Foam (70x21)
48 FP-PRO-FOAM-87*32-V1-R1 Wire Routing Plate Foam (70x32)
49 FP-PRO-FOAM-87*40-V1-R1 Wire Routing Plate Foam (70x40)
50 FP-PRO-PLATE-STRIP-V1-R1 Wire Routing Plate Rubber Strip
51 FP-GDE-WIRE-BASE-V1-R1 Wire Routing Plate Rubber Base
52 FP-GDE-WIRE-SHIELD-V1-R1 Wire Shield
53 FP-SCW-BTN-M5*16-V1-R1 M5x16 Wire Routing Plate Mounting Screw 3 Nm (26 in·lb) L
54 FP-CVR-MOTOR-FRONT-V1-R1 Front Motor Mount Cover
55 FP-PRO-SHTV5-SKD-V1-R1 SHTLv5 Skid Plate Protector
56 FP-PRO-SHTV5-DT-V1-R1 SHTLv5 Downtube Protector
57 FP-PRO-SHTV5-CS-V1-R1 SHTLv5 Chainstay Protector
58 FP-PRO-SHTV5-SS-V1-R1 SHTLv5 Seatstay Protector
59 FP-PRO-SHTV5-UR-V1-R1 SHTLv5 Upright Protector
60 FP-PRO-LL-50MM-V2-R1 Lower Link Protector
61 FP-BLT-FLT-M2.5*8-V1-R1 M2.5x8 Flat Head Charging Port Mounting Bolts
62 FRAME SIZE STICKER - XS/SM/MD/LG/XL Frame Size Sticker
Axles
NUMBER PART NUMBER DESCRIPTION TORQUE *
101 157MM THROUGH AXLE V5 157mm UDH Rear Axle 15 Nm (11 lb·ft) G
102 - 12mm Axle Washer (Included w/ Axle)
Bike Care
* PRODUCT TYPE RECOMMENDED PRODUCT
G Grease Motorex Bike Grease 2000
L Thread Locker** Loctite Thread Locker #243 (or equivalent)
G/L Grease (Bolt Shaft) / Thread Locker (Bolt Threads) See Above
A Anti-Seize Motorex Copper Paste
R Retaining Compound Loctite Retaining Compound #620 (or equivalent)
**Threadlocker should always be applied to the corresponding female threads for the bolt specified
