BIKE SET-UP
AIR PRESSURE
SUGGESTED REBOUND
SETTING FLOAT X
[bar] [psi]
< 8.3 <120 1 (9)
8.3 - 9.7 120-140 2 (8)
9.7 - 11 140-160 3 (7)
11 - 12.4 160-180 4 (6)
12.4 - 13.8 180-200 5 (5)
13.8 - 15.2 200-220 6 (4)
15.2 - 16.5 220-240 7 (3)
16.5 - 17.9 240-260 8 (2)
17.9 - 19.3 260-280 9 (1)
19.3 - 20.7 280-300 CLOSED
Clicks from OPEN (Clicks from CLOSED)
Setting Air Pressure on the Fox 38 Fork
• Fox recommends setting sag between 15% and 20% of the total fork travel. The Shuttle LT comes
with a 170mm fork, so the proper sag measurement is 25.5 - 34.0mm.
• The air pressure in the Fox 38 fork should not exceed 8.3 [bar] (120 [psi]).
• To achieve the proper sag, reference the chart below for an initial starting point.
RIDER WEIGHT
FOX 38
AIR PRESSURE
[kg] [lbs]
55 - 59 120 - 130 64 [psi] / 4.4 [bar]
59 - 64 130 - 140 68 [psi] / 4.7 [bar]
64 - 68 140 - 150 72 [psi] / 5.0 [bar]
68 - 73 150 - 160 76 [psi] / 5.2 [bar]
73 - 77 160 - 170 80 [psi] / 5.5 [bar]
77 - 82 170 - 180 84 [psi] / 5.8 [bar]
82 - 86 180 - 190 89 [psi] / 6.1 [bar]
86 - 91 190 - 200 93 [psi] / 6.4 [bar]
91 - 95 200 - 210 97 [psi] / 6.7 [bar]
95 - 100 210 - 220 102 [psi] / 7.0 [bar]
100 - 105 220 - 230 106 [psi] / 7.3 [bar]
105 - 109 230 - 240 110 [psi] / 7.6 [bar]
109 - 114 240 - 250 114 [psi] / 7.9 [bar]
Setting Rebound Damping on the Fox Float X
• Rebound is set from the most open (fully counter-clockwise) position.
• The rebound setting is determined by the air pressure in the shock.
• Refer to the table below for the suggested rebound setting. The number
in the chart refers to how many clicks in (clockwise) from the open setting
the rebound should be set. Fox sets rebound from the closed position, so
that has been provided in the table in parentheses.
FLOAT X REBOUND KNOB
