34 - ATR224 - DRR224 - User manual
Table of configuration parameters
GROUP A -
A.i n .1
- Analogue input 1
1
S E N .1
Sensor AI1 19
2
d .P.1
Decimal Point 1 19
3
d eG r.
Degree 19
4
L.L.i .1
Lower Linear Input AI1 19
5
u.L.i.1
Upper Linear Input AI1 19
6
P. v A .1
Potentiometer Value AI1 19
7
i.o.L.1
Linear Input over Limits AI1 20
8
o . c A .1
Offset Calibration AI1 20
9
G . c a .1
Gain Calibration AI1 20
10
L t c .1
Latch-On AI1 20
11
c . F L .1
Conversion Filter AI1 20
12
c . F r.1
Conversion Frequency AI1 20
13
L. c.E.1
Lower Current Error 1 20
14÷17 Reserved Parameters - Group A 20
GROUP C -
cm d.1
- Outputs and regulation Process 1
35
c.ou.1
Command Output 1 21
37
rEs .
Reserved 21
38
A c . t .1
Action type 1 21
39
c . H Y .1
Command Hysteresis 1 21
40
L.L.S.1
Lower Limit Setpoint 1 21
41
U . L . S .1
Upper Limit Setpoint 1 21
42
c . r e .1
Command Reset 1 21
43
c . S . e .1
Command State Error 1 21
44
c . L d .1
Command Led 1 21
45
c . d e .1
Command Delay 1 22
46
c . S . p .1
Command Setpoint Protection 1 22
48
a.ma.1
Automatic / Manual 1 22
49
i ni .S.
Initial State 22
51
i . S P.1
Initial Value Setpoint 1 22
52÷53 Reserved Parameters - Group C 22
GROUP E -
reG.1
- Autotuning and PID 1
73
t u n .1
Tune 1 23
74
s.d.t.1
Setpoint Deviation Tune 1 23
75
p. b.1
Proportional Band 1 23
76
i . t.1
Integral Time 1 23
77
d. t.1
Derivative Time 1 23
78
d . b .1
Dead Band 1 23
79
p.b.c.1
Proportional Band Centered 1 23
80
o.o.s.1
Off Over Setpoint 1 23
81
o.d.t.1
Off Deviation Threshold 1 23
82
c. t.1
Cycle Time 1 23
87
L.L.P.1
Lower Limit Output Percentage 1 24
88
U . L . p .1
Upper Limit Output Percentage 1 24
89
m . G . t .1
Max Gap Tune 1 24
90
m n . p .1
Minimum Proportional Band 1 24
91
m a . p .1
Maximum Proportional Band 1 24
92
mn.i.1
Minimum Integral Time 1 24
93
o . c . L .1
Overshoot Control Level 1 24
