4 Dimensions and Installation
51 mm
51 mm
90 mm
7
MAN TUN REM
C 1
A 1
A 2
PTC
NTC
Dima di foratura
46 x 46 mm
Frontal panel
cut-out
T
rou de panneau
Spessore suggerito 2 ÷ 6 mm
Suggested thickness 2 ÷ 6 mm
USB
ATR226
5 Electrical wirings
Although this controller was designed to resist electromagnetic interferences
in industrial environments, please observe following safety guidelines:
t 4FQBSBUFUIFDPOUSPMMJOFGSPNUIFQPXFSXJSFT
t "WPJEQSPYJNJUZPGSFNPUFDPOUSPMTXJUDIFTFMFDUSPNBHOFUJDDPOUBDUPSTQPXFSGVM
engines and in all instances use specic lters.
t "WPJEQSPYJNJUZPGQPXFSHSPVQTFTQFDJBMMZUIPTFXJUIQIBTFDPOUSPM
