Pixsys ATR226 User Manual

8 - ATR227 - User manual
5.1 Wiring diagram
ATR226-12ABC
Power Supply
Switching power supply with extended range 24..230 Vac/dc
±15% 50/60 Hz – 5,5 VA (galvanically insulated).
AN1 Analogue Input
For thermocouples K, S, R, J, T, E, N, B.
t $PNQMZXJUIQPMBSJUZ
t 'PSQPTTJCMFFYUFOTJPOTVTFDPNQFOTBUFEDBCMF
and terminals suitable for the thermocouples
used(compensated)
t 8IFOTIJFMEFEDBCMFJTVTFEJUTIPVMECFHSPVOEFEBUPOF
side only
For thermoresistances PT100, NI100
t 'PSUIFUISFFXJSFDPOOFDUJPOVTFXJSFTXJUIUIFTBNF
section
t 'PSUIFUXPXJSFDPOOFDUJPOTIPSUDJSDVJUUFSNJOBMTBOE
t 8IFOTIJFMEFEDBCMFJTVTFEJUTIPVMECFHSPVOEFEBUPOF
side only
RED
ROSSO
RED
ROSSO
WHITE
BIANCO
3
2
1
For thermoresistances NTC, PTC, PT500, PT1000 and linear
potentiometers
t 8IFOTIJFMEFEDBCMFJTVTFEJUTIPVMECFHSPVOEFEBUPOF
side only to avoid ground loop currents
