5. Starting Web Management
The following shows how to start up the Web Management of the Industrial
Managed Switch. Note the IndustrialManaged Switch is congured throughan
Ethernet connection. Please make sure the manager PC must be set to the
same IP subnet address.
For example, the default IP address of the Industrial Managed Switch is
192.168.0.100, then the manager PC should be set to 192.168.0.x (where x
is a number between 1 and254, except 100), andthe default subnetmask is
255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address: 192.168.0.100
Figure 5-1: IP Management Diagram
