Planet IGS-501T User Manual

15
2.2 Mounting Installation
This section describes how to install the Industrial Gigabit Ethernet
Switch and make connections to it. Please read the following topics and
perform the procedures in the order being presented.
2.2.1 DIN-Rail mounting
The DIN-Rail is screwed on the Industrial Gigabit Ethernet Switch
when out of factory. When need to replace the wall mount application
with DIN-Rail application on Industrail Gigabit Ethernet, please refer
to following gures to screw the DIN-Rail on the Industrial Gigabit
Ethernet Switch. To hang the Industrial Gigabit Ethernet Switch, follow
the below steps:

Planet IGS-501T Specifications

General

Brand	Planet
Model	IGS-501T
Category	Network Router
Language	English
