4.2 ConguringIPaddress
The Industrial Managed Switch is shipped with default IP address
shown below:
IP Address: 192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or modify a new IP address for the
Switch, please use the procedure as follows:
 Display of the current IP Address
1. At the “#” prompt, enter “show ip interface brief”.
2. The screen displays the current IP address shown in Figure 4-2.
Figure 4-2: IP Information Screen
 CongurationoftheIPAddress
3. At the “#” prompt, enter the following command and press <Enter>
as shown in Figure 4-3.
IGS-5225-4UP1T2S# congureterminal
IGS-5225-4UP1T2S(cong)#interface vlan 1
IGS-5225-4UP1T2S(cong-if-vlan)#ip address 192.168.1.100
255.255.255.0
The previous command would apply the following settings for the
Industrial Managed Switch.
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
