15
5.RecoveringBacktoDefaultConguration
IP address has been changed or admin password has been forgotten –
1. Power off the Industrial Managed Switch and remove all the existing connec-
tions.
2. Use the straight RJ45 cable to connect to port 1 and port 2 in the loop topology
as shown below:
3. Power on the Industrial Managed Switch and 6 LNK/ACT LEDs will be lit.
4. Resetting Industrial Managed Switch to the factory default is done when 6 LNK/
ACT LEDs are lit again.
5. Remove the RJ45 cable from port 1 and port 2.
6.ResettheIndustrialManagedSwitchto FactoryDefault conguration.The Indus-
trial Managed Switch will then reboot and load the default settings as shown
below:
Default Username: admin
Default Password: admin
Default IP Address: 192.168.0.100
Default Subnet Mask: 255.255.255.0
Default Gateway: 192.168.0.254
