User Manual of WDAP-C1800AX &WDAP-1800AX
- 35 -
Object Description
Enter the Gateway assigned by your ISP.
DNS Server
The DNS server information will be supplied by your
ISP.
DHCP
Select DHCP Client to obtain IP Address information
automatically from your ISP.
PPPoE
Select PPPOE if your ISP is using a PPPoE connection
and provide you with PPPoE user name and password
info.
PPTP
Enable or disable PPTP to pass through PPTP
communication data.
L2TP
Enable or disable L2TP to pass through L2TP
communication data.
WAN IP, whether obtained automatically or specified manually, should NOT be on
the same IP net segment as the LAN IP; otherwise, the router will not work properly.
In case of emergency, press the hardware-based "Reset" button.
4.2.2 LAN
This page is used to configure the parameters for local area network which connects to the LAN port of
your router as shown in Figure 4-27. Here you may change the settings for IP address, subnet mask,
DHCP, etc.
Figure 4-27: LAN Setup
Object Description
IP Address
The LAN IP address of the router and default is 192.168.1.1.
Net Mask
Default is 255.255.255.0.
