User Manual of WDAP-C1800AX &WDAP-1800AX
- 48 -
4.3.2 MAC Filtering
Entries in this table are used to restrict certain types of data packets from your local network or Internet
through the router. Use of such filters can be helpful in securing or restricting your local network as
shown in Figure 4-39.
Figure 4-39: MAC Filtering
Object Description
Enable MAC Filtering
Set the function as enable or disable.
When the function is enabled, the router will block traffic of the MAC
address on the list.
Interface
Select the function works on LAN, WAN or both. If you want to block
a LAN device’s MAC address, please select LAN, vice versa.
MAC Address
Input a MAC address you want to control, such as
A8:F7:E0:00:06:62.
Add
When you input a MAC address, please click the “Add” button to add
it into the list.
