User’s Manual of WGSW-20160HP/WGSW-24040HP series
1.4 Product Features
WGSW-20160HP Physical Port
16-Port 10/100/1000Base-T RJ-45 copper with IEEE 802.3at / 802.3af Power over Ethernet Injector function
4 10/100/1000Mbps TP and SFP shared combo interfaces, SFP(Mini-GBIC) supports 100/1000Mbps Dual mode,
shared with Port-17 to Port-20
RS-232 DB9 console interface for basic management and setup
WGSW-24040HP/WGSW-24040HP4 Physical Port
24-Port 10/100/1000Base-T RJ-45 copper with IEEE 802.3at / 802.3af Power over Ethernet Injector function
4-Port 10/100/1000Mbps TP and SFP shared combo interfaces, SFP(Mini-GBIC) supports 100/1000Mbps Dual mode,
shared with Port-21 to Port-24
RS-232 DB9 console interface for basic management and setup
Power over Ethernet
■ Comply with IEEE 802.3at High Power over Ethernet End-Span PSE
■ Comply with IEEE 802.3af Power over Ethernet End-Span PSE
■ Up to 16 ports for IEEE 802.3af / 802.3at devices powered (For WGSW-20160HP only)
■ Up to 24 ports for IEEE 802.3af / 802.3at devices powered (For WGSW-24040HP series only)
■ Support PoE Power up to 30.8 Watts for each PoE ports
■ Auto detect powered device (PD)
■ Circuit protection prevent power interference between ports
■ Remote power feeding up to 100m
■ PoE Management
− Total PoE power budget control
− Per port PoE function enable/disable
− PoE Port Power feeding priority
− Per PoE port power limit
− PD classification detection
− PD Alive-check
− PoE schedule
Layer 2 Feature
■ Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
■ High performance of Store-and-Forward architecture and runt/CRC filtering eliminates erroneous packets to optimize
the network bandwidth
■ Storm Control support:
− Broadcast / Multicast / Unknown-Unicast
