User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.18.5 RMON Event Detail
This Page provides an overview of RMON event entries; screen in Figure 4-18-5 appears.
Figure 4-18-5: Detailed RMON Event ID Page Screenshot
The Page includes the following fields:
Object Description
• LogTime
Indicates Event log time.
• LogDescription
Indicates the Event description.
Buttons
: Click to refresh the Page immediately.
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
4.18.6 RMON Event Status
This Page provides an overview of RMON Event table entries.Each Page shows up to 99 entries from the Event table, default
being 20, selected through the "entries per Page" input field. When first visited, the web Page will show the first 20 entries from
the beginning of the Event table. The first displayed will be the one with the lowest Event Index and Log Index found in the Event
table table; screen in Figure 4-18-6 appears.
Figure 4-18-6: RMON Event Overview Page Screenshot
