User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.16 Power over Ethernet
Providing up to 16 PoE, in-line power interfaces, the WGSW-20160HP PoE Switch can easily build a power central-controlled IP
phone system, IP Camera system, AP group for the enterprise. For instance, 16 camera / AP can be easily installed around the
corner in the company for surveillance demands or build a wireless roaming environment in the office. Without the power-socket
limitation, the WGSW-20160HP PoE Switch makes the installation of cameras or WLAN AP more easily and efficiently.
Since the WGSW-20160HP and WGSW-24040HP series have the same PoE configuration interface,
except PoE port supported and PoE power budget as following table, so we still pick up
WGSW-20160HP to be example for describing PoE interface operation.
Model Name PoE Port Supported Totally PoE Power Budget
WGSW-20160HP 16 230 Watts
WGSW-24040HP 24 220 Watts
WGSW-24040HP4 24 440 Watts
Figure 4-16-1: Power over Ethernet Status
