User Manual of WRE-1200
36
IP Address
Displays the IP address of this device. Click “Refresh” to update this
value.
Default Gateway
Displays the IP address of the default gateway.
DNS
IP address of DNS (Domain Name Server)
DHCP Server
IP address of DHCP Server.
Wired LAN Port
Displays LAN Port 1.
Status
Displays the status of the LAN port (connected or disconnected).
Connection Status
Displays the status of the 2.4GHz and 5GHz wireless (connected or no
connection).
Source SSID
Display the SSID of source AP.
Extended SSID
Display the SSID of this range extender.
Authentication Method
Displays the authentication method for the specified SSID.
Encryption Type
Displays the encryption type for the specified SSID.
MAC Address
Displays the range extender’s MAC address.
Channel
Displays the channel number the specified wireless frequency is using
for broadcast.
Transmit Power
Displays the wireless radio transmit power level as a percentage bar.
Refresh
Click to refresh all information.
