Inside
Outside
Additional bracket
required (not supplied)
A: 7 ⅞"
D: 90°/105° Travel time: 21 to 24 sec
B
6 ⅝"
C: 4 ¾"
Don’t install the Swing gate
to open into public access areas.
To reduce the risk of entrapment leave enough clearance in between the gate and
adjacent structures during opening.
OPEN OUTSIDE INSTALLATION:
