ACTP715
Types of Installations
OPEN INSIDE INSTALLATION IN inches (mm)
A*
Min 5
1
/
8
”(130)
Max 7
7
/
8
” (200)
B*
Min 6
11
/
16
” (170)
Max 11
7
/
16
” (290)
A
6
11
/
16
” (170)
7
7
/
8
” (200)
7
7
/
8
” (200)
5
1
/
8
” (130)
B
6
11
/
16
” (170)
7
7
/
8
” (200)
6
11
/
16
” (170)
11
7
/
16
” (290)
C
3
15
/
16
” (100)
5
1
/
8
” (130)
3
15
/
16
” (100)
8
5
/
8
” (220)
D
90°
95°
120°
90°
E
4
23
/
32
”
(120)
F
35
13
/
16
”
(910)
*Use measurements between minimum and maximum.
A
E
F
B
C
D: 90°/120° Travel time: 21 to 25 sec
Inside
Outside
To obtain desired dimension B,
cut the Back Mounting Bracket.
OPEN INSIDE INSTALLATION:
