5.0/5.7/6.0L/8.1L General Information 1 - 9
MEFI 4 - PCM
HARNESS TEST ADAPTER KIT
Used to make electrical test connections in current Weather
Pack, Metri-Pack and Micro-Pack style terminals.
20’ DIAGNOSTIC CONNECTOR EXTENSION CABLE
Extension cable to go between the scan tool and the DLC
on the engine harness.
FUEL LINE QUICK-CONNECT SEPARATOR
Used to release fuel line quick-connect fi ttings.
INJECTOR TESTER
Separately energizes each injector to compare for equal
fuel pressure drops over a constant time interval.
TIMING LIGHT
Must have inductive signal pickup.
Special Tools (3 of 3)
J 35616
TA 06076
J 39021
J 34186
4AMP
MP
AMP
2.5 AMP
6.5 AMP
LOW BATTERY
READY TO TEST
TEST IN PROGRESS
INJECTOR
VOLTS
+
-
J-39021
PUSH TO TEST
KENT-MOORE
J 37088-A/BT-9171
