6.0L Fuel Metering System 3B - 3

MEFI 4 - PCM

Figure 3-2 - Fuel Control Cell (FCC)

Figure 3-1 - Fuel Metering System (Typical)

Figure 3-3 - Low Pressure Fuel Pump

M4054P

2-12-04

FUEL

TANK

PRESS.

REG.

FUEL

FILTER

LOW-

PRESSURE

FUEL

PUMP

FUEL

CONTROL

CELL

FUEL RAIL ASSEMBLY

ENGINE

Fuel Control Cell Fuel System

(Returnless Fuel Rail)
