6.0L Fuel Metering System 3B - 15
MEFI 4 - PCM
4. Discard the injector retainer clip (1).
5. Remove the injector O-ring seals (2), (4) from both
ends of the injector. Discard the O-ring seals.
Install or Connect
Important: When ordering new fuel injectors, be sure
to order the correct injector for the application being
serviced.
The fuel injector assembly (1) is stamped with a part
number identifi cation (2). A four digit build date code (3)
indicates the month (4), day (5), year (6) and the shift (7)
that built the injector.
351185
351196
Fuel Injector Replacement
Remove or Disconnect
Important: The engine oil may be contaminated with fuel
if the fuel injectors are leaking.
1. Remove the fuel rail assembly. Refer to Fuel Rail
Assembly Replacement.
2. Remove the injector retainer clip (4).
3. Insert the fork of J 43013, the fuel injector assembly
removal tool, between the fuel rail pod and the 3
protruding retaining clip ledges. Use a prying motion
while inserting the tool in order to force the injector
out of the fuel rail pod.
350543
