PLUSOPTIX S16 - Page 21

Page 21/22
Immunity test
Testing level acc. to
IEC 60601
Conformity results
Electromagnetic environment –
Instructions
Conducted RF disturbances
IEC 61000-4-6
3 V
0.15 MHz – 80 MHz
6 V
in ISM and amateur
radio bands between
0.15 MHz and 80 MHz
80 % AM at 1 kHz
3 V
0.15 MHz – 80 MHz
6 V
in ISM and amateur
radio bands between
0.15 MHz and 80 MHz
80 % AM at 1 kHz
120V / 60 Hz
230V / 50 Hz
3 V
0.15 MHz – 80 MHz
6 V
in ISM and amateur
radio bands between
0.15 MHz and 80 MHz
80 % AM at 1 kHz
3 V
0.15 MHz – 80 MHz
6 V
in ISM and amateur
radio bands between
0.15 MHz and 80 MHz
80 % AM at 1 kHz
120V / 60 Hz
230V / 50 Hz
Portable and mobile radio equipment
must not be operated in a distance
to „plusoptiX 16“ (including the electrical
lines) less than the recommenced safe
distance calculated using the
appropriate equation for the
transmission frequency.
Recommended safe distance:
d=(3.5/10) x √ P
d=(3.5/10) x √ P 80MHz - 800MHz
d=(7/10) x √ P 800MHz – 2.7GHz
where P is the maximum output power
rating of the transmitter in watts (W) as
indicated by the transmitter
manufacturer and “d” is the
recommended safe distance in metres
(m).
The field strength of fixed RF
transmitters
as determined by a site survey should
be less than the compliance level in
each frequency range.
Interference may occur in the vicinity of
equipment marked by the
symbol shown.
Radio-frequency electromagn.
fields
IEC 61000-4-3
10 V/m
80 MHz - 2.7GHz
80% AM, 1KHz
27 V/m
385 MHz
PM 50%, 18 Hz
28 V/m
450 MHz
PM 50%, 18 Hz
9 V/m
710,745,780 MHz
PM 50%, 217 Hz
28 V/m
810, 870, 930 MHz
PM 50%, 18 Hz
28 V/m
1720, 1845, 1970 MHz
PM 50%, 217 Hz
28 V/m
2450 MHz
PM 50%, 217 Hz
9 V/m
5240, 5500, 5785 MHz
PM 50%, 217 Hz
10 V/m
80 MHz - 2.7GHz
80% AM, 1KHz
27 V/m
385 MHz
PM 50%, 18 Hz
28 V/m
450 MHz
PM 50%, 18 Hz
9 V/m
710,745,780 MHz
PM 50%, 217 Hz
28 V/m
810, 870, 930 MHz
PM 50%, 18 Hz
28 V/m
1720, 1845, 1970 MHz
PM 50%, 217 Hz
28 V/m
2450 MHz
PM 50%, 217 Hz
9 V/m
5240, 5500, 5785 MHz
PM 50%, 217 Hz
COMMENT 1 At 80 MHz and 800 MHz, the higher frequency range applies.
COMMENT 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
