PMC PH-2 - TECHNICAL SPECIFICATIONS; Electrical Specifications

PH/PHX-2 Manual
10
TECHNICAL SPECIFICATIONS
Electrical
Main Voltage: __________________________________________3 x 208-230V, 50/60Hz
Electrical Consumption: PH-2, 2000 PSI (2 x 3.75 kW Heaters) _______ 40 A @ 3 x 230V
Electrical Consumption: PH-2, 2000 PSI (2 x 4.50 kW Heaters) _______ 46 A @ 3 x 230V
Electrical Consumption: PH-2, 2000 PSI (2 x 5.25 kW Heaters) _______ 51 A @ 3 x 230V
Electrical Consumption: PHX-2, 3000 PSI (2 x 5.25 kW Heaters) _______ 51 A @ 3 x 230V
Main Voltage: __________________________________________1 x 208-230V, 50/60Hz
Electrical Consumption: PH-2, 2000 PSI (2 x 3.75 kW Heaters) _______ 61 A @ 1 x 230V
Electrical Consumption: PH-2, 2000 PSI (2 x 4.50 kW Heaters) _______ 67 A @ 1 x 230V
Electrical Consumption: PH-2, 2000 PSI (2 x 5.25 kW Heaters) _______ 72 A @ 1 x 230V
Electrical Consumption: PHX-2, 3000 PSI (2 x 5.25 kW Heaters) _______ 72 A @ 1 x 230V
Main Voltage: _____________________________________________ 3 x 380V, 50/60Hz
Electrical Consumption: PH-2, 2000 PSI (2 x 3.75 kW Heaters) _______ 40 A @ 3 x 380V
Electrical Consumption: PH-2, 2000 PSI (2 x 4.50 kW Heaters) _______ 46 A @ 3 x 380V
Electrical Consumption: PH-2, 2000 PSI (2 x 5.25 kW Heaters) _______ 51 A @ 3 x 380V
Electrical Consumption: PHX-2, 3000 PSI (2 x 5.25 kW Heaters) _______ 51 A @ 3 x 380V
Material Heater Power: PH-2 (2 x 3.75 kW)________________________________ 7.5 kW
Material Heater Power: PH-2 (2 x 4.50 kW)________________________________ 9.0 kW
Material Heater Power: PH-2 (2 x 5.25 kW)_______________________________ 10.5 kW
Material Heater Power: PHX-2 (2 x 5.25 kW) _____________________________ 10.5 kW
Hose Transformer Power: (70 V) _________________________________________ 2 KVA
Hose Transformer Power: (90 V) _________________________________________ 3 KVA
Hose Transformer Power: (120 V) ________________________________________ 5 KVA
Electrical Motor Power: PH-2 _____________________________________________ 3 hp
Electrical Motor Power: PHX-2 ___________________________________________ 5 hp
CAUTION! Inside the console is a Terminal Strip for
connecting the main power (wire not supplied) to the PH
Series Proportioner. This electrical connection must be
made only by a qualified electrician.
