PMC PH-2 - Hydraulic Manifold Assembly

PH/PHX-2 Manual
55
HYDRAULIC MANIFOLD ASSEMBLY
HYDRAULIC MANIFOLD ASSEMBLY
HI-05335
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
HI-05070-3
HYDRAULIC MANIFOLD
2
2
HI-05007
6 ORB X 6 JIC
3
1
HI-05324
6 ORB X ½ JIC; 90 DEG
4
1
HI-05348
6 ORB EXTENTION
5
1
HI-05350
6 JIC 6 ORB "T"
6
1
HI-05040
PRESSURE GAUGE 0-2000 PSI
7
1
HI-05006-6
1/4 NPT X 6 JIC GAUGE FITTING
8
1
HI-05349
6 JIC X 8 JIC
