PH/PHX-2 Manual
18
Follow the recommended procedure in the indicated order to install the Proportioner:
1. Insert the main power cable by passing it through the wire stop at the bottom of the
electrical console and connect as shown in the diagram above.
2. Fill the Hydraulic Reservoir with 10 gallons (37 Liters) of approved hydraulic fluid. See
page 51 for oil specifications.
NOTE! Do not fill the tank to maximum capacity; use the Visual Level
Indicator on the tank to make sure the amount of hydraulic fluid is not
more than 10 gal (37 L) or 80% of the tank maximum capacity.
3. Check the level of the hydraulic fluid in the Hydraulic Pump Case: Disconnect the
Hydraulic Hose from the 90 fitting and remove Fitting from Hydraulic Case. Add fluid
as required. Reattach Fitting and Hydraulic Hose. Turn the hydraulic pressure control
knob counter clockwise until it stops, that is the lowest hydraulic pressure setting.
