PMC PH-2 - Page 72

PH/PHX-2 Manual
72
PUMPLINE ASSEMBLY
PL-10
ITEM
QTY
PART NUMBER
DESCRIPTION
1
2
PAX-044
SINGLE PL-PAX PUMP (SEE PAGE 65)
2
1
PU-07002
BRACKET, PAX
3
16
FLOOR STOCK
¼-20 X 1 HEX SHCS
4
2
HI-05338
FLANGE, PAX
5
4
FLOOR STOCK
3/8-16 X 3 HEX SHCS
6
4
PU-07009
STAND OFF, PUMPLINE
7
1
PU-07001
MALE CLEVIS
8
1
PU-07003
SHAFT, PA LUBE
9
2
PU-05007
CLEVIS PIN
10
1
HI-05336
HYDRAULIC CYLINDER ASSY, PH(X)-2
(SEE PAGE 59)
11
2
HI-05011
9/16-18 O-RING X 9/16-18 JIC
12
4
FLOOR STOCK
3/8-16 X 6 HEX SHCS
13
1
OR-806
O-RING #120 VITON
14
1
PU-07004
LUBE SECTION, PAX
15
1
OR-807
O-RING #137 VITON
