PH/PHX-2 Manual
77
PREHEATER ASSEMBLY
PH-21 (3750 W)
PH-22 (4500 W)
PH-23 (5250 W)
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
GM-07000
HEATER BODY
2
2
HI-05020
THERMOCOUPLE NUT
3
3
GM-07001
HEATER BLOCK MOUNT
4
3
GM-07002
HEATER BLOCK SPACER
5
2
GM-07003
PHENOLIC STANDOFF, HEATER BODY
6
2
HI-05344
6 ORB X 6 JIC SW
7
2
HI-05007
6 ORB X 6 JIC
8
6
HI-05034
1-1/16-12 O-RING PLUG
9
4
HI-05070-4
6 ORG PLUG
10
2
HI-05021
THERMOCOUPLE TYPE E
11
6
GM-05423-1250
FIRE ROD; 1250W, 3/4 NPT, 17.5
GM-05423-1500
FIRE ROD; 1500W, 3/4 NPT, 17.5
GM-05423-1750
FIRE ROD; 1750W, 3/4 NPT, 17.5
12
6
GM-05423-7
SPRING; 18" CBN STEEL
13
1
EL-00006A
SWITCH; THERMAL LIMIT OVERTEMP
14
2
FLOOR STOCK
#6-32 X 1/4 HEX SHCS
15
4
FLOOR STOCK
1/4-20 X 5/8 ROUND HEAD BOLT
16
6
FLOOR STOCK
1/4 PLAIN WASHER
17
6
FLOOR STOCK
1/4-20 X 1 HEX BOLT
