PH/PHX-2 Manual
81
MOTOR LINE ASSEMBLY
ML-1 (3HP; 3PH; 60HZ)
ML-4 (5HP; 3PH; 60HZ)
ITEM
QTY
PART
NUMBER
DESCRIPTION
1
1
EL-05224
ELECTRIC MOTOR; 3HP; 3PH; 60HZ (ML-1)
1
EL-05223
ELECTRIC MOTOR; 5HP; 3PH; 60HZ (ML-4)
2
1
HI-05001
BELL HOUSING
3
1
HI-00065-02
MAGNALOY HUB
4
1
HI-00065-01
MAGNALOY INSERT (ML-1)
HI-00067
MAGNALOY INSERT 9.45HP (ML-4)
5
1
HI-00065-03
MAGNALOY HUB
6
1
HI-05004
HYDRAULIC PUMP
7
1
HI-05006-3
1-1/16-12 O-RING X ¾-16 JIC
8
1
HI-05007
3/8 JIC X 6 ORB 90 DEG
9
4
FLOOR STOCK
7/16 PLAIN WASHER
10
4
FLOOR STOCK
7/16 LOCK WASHER
11
4
FLOOR STOCK
1/2-13 X 1 HEX BOLT
12
2
FLOOR STOCK
3/8 LOCK WASHER
13
2
FLOOR STOCK
3/8-16 X 1.5 HEX BOLT
14
1
FLOOR STOCK
ACCESS COVER
15
1
HI-05009
1-1/16-12 OUTLET FLANGE
16
1
HI-05010
1” NPT INLET FLANGE
17
1
HI-00049A
1X16 BLACK PIPE FOR HYDRAULIC
18
1
HI-05004-1
CONTROL KNOB; HYDRAULIC PUMP
