PH-20/PHX-20 Manual
15
NOTE! Do not fill the tank to maximum capacity; Make sure the amount
of hydraulic fluid is not more than 12 gal or 80% of the tank maximum
capacity.
3. Check the level of the hydraulic fluid in the Hydraulic Pump Case: Disconnect the
Hydraulic Hose from the 90 fitting and remove Fitting from Hydraulic Case. Add fluid
as required. Reattach Fitting and Hydraulic Hose. Turn the hydraulic pressure control
knob counter clockwise until it stops, that is the lowest hydraulic pressure setting.
Check Fluid Level Hydraulic Pressure control Knob
