PH-20/PHX-20 Manual
49
HEATER PARTS
PART NUMBER DESCRIPTION QTY PER HEATER
PH-16
COMPLETE “A” SIDE HEATER, PH-20
1
PH-17
COMPLETE “R” SIDE HEATER, PH-20
1
PH-18
COMPLETE “A” SIDE HEATER, PHX-20
1
PH-19
COMPLETE “R” SIDE HEATER, PHX-20
1
GM-06424-1
HEATER BODY
2
GM-06424-2
PHONOLIC WASHER
4
GM-05423-1250
HEATER CARTRIDGE, PH-20
3
GM-05423-1500
HEATER CARTRIDGE, PHX-20
3
GM-05423-7
SPRING
3
KT-05020
THERMOCOUPLE KIT
1
HI-05034
O-RING PLUG
3
EL-00006A
OVER TEMP SWITCH
1
HI-05036
¼” PIPE PLUG
2
HI-05026
OUTLET HEATER FITTING “R”
1
HI-05027
OUTLET HEATER FITTING “A”
1
HI-05059
INLET HEATER FITTING
1
HI-05088
¼”M x ¼”F, NPT FITTING
1
GP-00100-3
¼” RUNNING TEE
1
HI-05028
GAUGE, 0-3000 PSI (PH-20)
1
HI-00035
GAUGE, 0-5000 PSI (PHX-20)
1
REVERSING SWITCH PARTS
PART NUMBER DESCRIPTION QTY
EL-00021
REVERSING SWITCH
1
RM-216
REVERSING SWITCH BRACKET
1
RM-217
REVERSING SWITCH PLATE
1
RM-218
REVERSING SWITCH COVER, FRONT
1
RM-219
REVERSING SWITCH COVER, BACK
1
RM-220
REVERSING SWITCH TRIP ARM
1
RM-221
REVERSING SWITCH TRIP SHAFT
1
