PMC PH Series - Hoses

PH-20/PHX-20 Manual
52
PART NUMBER DESCRIPTION QTY
MA-00014A
3/8 x 50’ LOW PRESSURE HOSE,2250 psi
1
MA-00014-TC
3/8 x 50’ LOW PRESSURE HOSE,2250 psi W/TC WIRE
1
MA-00040A
¼ x 10” GUN HOSE ASSY W/SCUFF JACKET 3500psi
1
MA-00039A
3/8 x 50’ HIGH PRESSURE HOSE,3500 psi
1
MA-00039A-TC
3/8 x 50’ HIGH PRESSURE HOSE,3500 psi W/TC WIRE
1
MA-00014A-TC-35
3/8 x 35’ LOW PRESSURE HOSE,2250 psi W/TC WIRE
1
MA-00039A-TC-35
3/8 x 35’ HIGH PRESSURE HOSE,3500 psi W/TC WIRE
1
MA-00014A-A-50
3/8 x 50’ “A” SIDE LOW PRESSURE HOSE,2250 psi
1
MA-00014A-R-50
3/8 x 50’ “R” SIDE LOW PRESSURE HOSE,2250 psi
1
MA-00040A-A
¼ x 10” “A” SIDE GUN HOSE, 3500psi
1
MA-00040A-R
¼ x 10” “R” SIDE GUN HOSE, 3500psi
1
MA-00005A-50
50’ SCUFF JACKET
1
MA-00005A-35
35’ SCUFF JACKET
1
MA-00005A-10
10’ SCUFF JACKET
1
HYDRAULIC/MACHINE HOSES
HI-05047-1
HOSE, FLUID PUMP TO HEATER 16.5”
2
HI-05047-2
HOSE, HYDRAULIC PUMP TO TANK 9”
1
HI-05047-3
HOSE, BOTTOM HYDRAULIC CYL. TO MANIFOLD 17.5”
1
HI-05047-4
HOSE, TOP HYDRAULIC CYL. TO MANIFOLD 13”
1
HI-05013
HOSE, HYDRAULIC PUMP OUTLET 24”
1
HOSE TEMPERATURE SENSING UNIT (TSU)
PART NUMBER DESCRIPTION QTY
EL-51A
TSU ASSEMBLY
1
EL-51A-2
TSU PROBE REPLACEMENT
1
EL-00051A-1
TSU BODY
1
EL-00051A-3
FITTING, 1/8 NPT x #4 JIC SWIVEL
1
EL-00051A-4
FITTING, 1/4 NPT x #5 JIC MALE (A)
1
EL-00051A-5
FITTING, 1/4 NPT x #6 JIC SWIVEL (R)
1
EL-00051A-6
FITTING, 1/4 NPT x #6 JIC (R)
1
EL-00051A-7
FITTING, 1/4 NPT x #5 JIC SWIVEL (A)
1
EL-00051A-8
INSULATION
1
HI-02 HYDRAULIC MANIFOLD ASSEMBLY
