PH-20/PHX-20 Manual

PART NUMBER DESCRIPTION QTY

HI-05070-1

MANIFOLD, HYDRAULIC

HI-05070-2

DRAIN TUBE ¼”

HI-05040-2

GAUGE, 0-2000 psi Bottom mount

HI-05003

DIRECTIONAL VALVE

GP-00100-5

ELBOW

HI-05038

FITTING,

HI-05200 HYDRAULIC CYLINDER

PART NUMBER DESCRIPTION QTY

HI-05200-1

PISTON

HI-05200-2

CYLINDER

HI-05200-3

PORT BLOCK

HI-05200-5

Bolt, TIE ROD

HI-05201

MOUNTING PLATE

HI-05202

MOUNTING PLATE, PUMP YOKE

HI-002

NUT, YOKE

HI-05025-1*

U CUP

HI-05025-2*

RING, BACK UP

HI-05025-3*

RING, WEAR

HI-05025-4*

ROD WIPER

HI-05025-5*

SEAL, SHAFT

HI-05025-6*

RING, BACK UP

OR-00039A*

O-RING

OR-00040A*

O-RING

NOTE: * Included in Hydraulic Rebuild Kit KT-05025
