PMC PH Series - Page 51

PH-20/PHX-20 Manual
51
HYDRAULIC TANK PARTS
PART NUMBER DESCRIPTION QTY
RM-213
TANK LID
1
HI-00014-04A
GASKET, TANK TOP
1
TN-05704
CASTERS
4
HI-00002-A
GROMMET, TANK TOP
1
HI-05048
DRAIN PLUG
1
RM-212
TRANSFORMER DOOR
1
\
Y-STRAINER PARTS
PART NUMBER DESCRIPTION QTY
YS-1
Y-STRAINER ASSY, A SIDE
1
YS-2
Y-STRAINER ASSY, R SIDE
1
RA-00074-00A
Y-STRAINER (60 MESH)
1
RA-00078A
BALL VALVE ¾”
1
HI-05015
¾ NPT ELBOW
1
HI-05016
¾ “ x ¾” SWIVEL FITTING “R” SIDE
1
HI-05017
¾” HEX NIPPLE
1
HI-05018
¾ “ x ½” SWIVEL FITTING “A” SIDE
1
SP-00009A
REPLACEMENT SPRING
1
RA-00074-02A
REPLACEMENT GASKET
1
RA-00074-03-80A
REPLACEMENT SCREEN, 80 MESH
1
RA-00074-03-60A
REPLACEMENT SCREEN, 60 MESH
1
RA-00074-03-30A
REPLACEMENT SCREEN, 30 MESH
1
PRESSURE GAUGES
PART NUMBER DESCRIPTION QTY
HI-00035
PHX PRESSURE GAUGE, FLUID 0-5000 PSI
2
HI-05028
PH PRESSURE GAUGE, FLUID 0-3000 PSI
2
HI-05040-2
PRESSURE GAUGE, HYDRAULIC 0-2000PSI
1
HEATED HOSES and REPLACEMENTS
